rn-executorch-card-scanner: On-device credit card OCR for React Native

·3 mins
Table of Contents

On-device credit/debit card scanner for React Native using ExecuTorch EasyOCR and Vision Camera. Runs entirely on-device — no server, no API keys, no data leaves the phone.

How it works #

The scanner uses two ML models from the EasyOCR project, running via Meta’s ExecuTorch runtime:

ModelRoleDescription
CRAFTDetectorFinds text regions using heatmap-based detection
CRNNRecognizerReads text from detected regions

The camera captures photos at a configurable interval. Each frame goes through OCR, then a smart parser extracts card fields (number, expiry, holder name, bank). A tick-based accumulator requires multiple consistent readings before locking a field — this filters out OCR noise and produces reliable results.

graph TD A[Camera Capture] --> B[CRAFT + CRNN OCR] B --> C[Card Parser] C --> D{Accumulator locked?} D -->|No| A D -->|Yes| E[ScannedCard Result]

Key design decisions:

  • Bbox spatial reasoning: Card numbers often split across multiple OCR detections. The parser uses bounding box Y-coordinates (30px threshold) to group text on the same line and reconstruct full numbers.
  • Digit-level expiry accumulation: Each digit of MM/YY is tracked independently — a single sighting locks that digit permanently, since expiry numbers are small and rarely misread.
  • OCR character correction: Common OCR mistakes (O→0, I→1, S→5, etc.) are corrected via a configurable character map.

Known limitations #

  • Low-contrast cards: Cards without raised/embossed numbers or low contrast between text and background may not parse reliably
  • Memory: ~1.4 GB RAM while scanner is active (OCR models are large)
  • APK size: Adds ~180 MB to your APK (model weights)
  • First run: Models (~45 MB) are downloaded from HuggingFace and cached locally
  • Performance: ~1s on Galaxy S24, ~2.8s on iPhone SE 3 per inference cycle

Setup #

# Peer dependencies
npm install react-native-vision-camera react-native-executorch

# For Expo
npm install @react-native-executorch/expo-adapter expo-file-system expo-asset

# The package
npm install rn-executorch-card-scanner

Add .pte and .bin to Metro asset extensions:

// metro.config.js
const { getDefaultConfig } = require('expo/metro-config');
const config = getDefaultConfig(__dirname);
config.resolver.assetExts.push('pte', 'bin');
module.exports = config;

Drop-in component #

import { CardScannerView, type ScannedCard } from 'rn-executorch-card-scanner';

<CardScannerView
  config={{ debug: true, timeout: 60 }}
  onResult={(card) => console.log(card)}
  onClose={() => {}}
/>

Custom UI with hook #

import { useCardScanner } from 'rn-executorch-card-scanner';

const scanner = useCardScanner({ timeout: 90, scanInterval: 1500, requiredTicks: 3 });
// Use scanner.cameraRef, scanner.displayFields, scanner.countdown, etc.

Testing on Android emulator #

Sample card images are included in the repo under docs/sample-cards/.

  1. Open the emulator’s Settings > Camera
  2. Add a sample card image to the wall option
  3. Open the card scanner in your app
  4. In the camera view, hold Alt and use WASD keys to navigate to the room where the card is displayed on the wall
  5. Point the camera at the card to test scanning

This avoids needing a physical card during development.
